Read this article to learn about the cloning vectors and the factors considered for the treatment of cloning vector system.
The seven factors considered for the treatment of cloning vector system are: (1) Plasmids (2) Bacteriophage I as a Cloning Vector (3) Cosmids (4) Fosmids (5) Phagemid (6) Shuttle Vectors and (7) Artificial Chromosomes.
Cloning Vectors:
For the cloning of any molecule of DNA it is necessary for the DNA to be incorporated into a cloning vector. These are DNA elements that may be stably maintained and propagated in a host organism for which the vector has replication functions.
A typical host organism is a bacterium, such as Escherichia coli, that grows and divides rapidly. Any vector with a replication origin in E. coli will replicate efficiently (together with any incorporated DNA). Thus, any DNA cloned into a vector will enable the amplification of the inserted foreign DNA fragment and also allow any subsequent analysis to be undertaken. In this way the cloning process resembles the PCR, although there are some major differences between the two techniques. By cloning, it is possible not only to store a copy of any particular fragment of DNA but also to produce unlimited amounts of it.
The vectors used for cloning vary in their complexity, ease of manipulation, selection and the amount of DNA sequence they can accommodate (the insert capacity). Vectors have in general been developed from naturally occurring molecules such as bacterial plasmids, bacteriophages or combinations of the elements that make them up, such as cosmids.
For gene library constructions there is a choice and trade-off between various vector types, usually related to the ease of the manipulations needed to construct the library and the maximum size of foreign DNA insert of the vector. Thus vectors with the advantage of large insert capacities are usually more difficult to manipulate.
Although there are many more factors to be considered, which are indicated in the following treatment of vector systems:
1. Plasmids,
2. Bacteriophage I as a Cloning Vector,
3. Cosmids,
4. Fosmids,
5. Phagemid,
6. Shuttle Vectors and
7. Artificial Chromosomes.
1. Plasmids:
Plasmids are naturally occurring; circular, extra chromosomal DNA molecules. Natural strains of the common colon bacterium Escherichia isolated from various sources harbour diverse plasmids. Often these plasmids carry genes specifying novel metabolic activities that are advantageous to the host bacterium.
These activities range from catabolism of unusual organic substances to metabolic functions that endow the host cells with resistance to antibiotics, heavy metals, or bacteriophages. Plasmids that are able to perpetuate themselves in E. coli, the bacterium favoured by bacterial geneticists and molecular biologists, have become the darlings of recombinant DNA technology.
Because restriction endonuclease digestion of plasmids can generate fragments with overlapping or “sticky” ends, artificial plasmids can be constructed by ligating different fragments together. Such artificial plasmids were among the earliest recombinant DNA molecules. These recombinant molecules can be autonomously replicated, and hence propagated, in suitable bacterial host cells, provided they still possess a site signalling where DNA replication can begin (also called origin of replication or ori sequence).
I. Plasmids as Cloning Vectors:
The idea arose that “foreign” DNA sequences could be inserted into artificial plasmids and that these foreign sequences would be carried into E. coli and propagated as part of the plasmid. That is, these plasmids could serve as cloning vectors to carry genes. (The word vector is used here in the sense of “a vehicle or carrier.”) Plasmids useful as cloning vectors possess three common features: a replicator, a selectable marker, and a cloning site (Fig. 4.1).
A replicator is an origin of replication, or ori. The selectable marker is typically a gene conferring resistance to an antibiotic. Only those cells containing the cloning vector will grow in the presence of the antibiotic. Therefore, growth on antibiotic containing media “selects for” plasmid-containing cells.
Typically, the cloning site is a sequence of nucleotides representing one or more restrictions in endonuclease cleavage sites. Cloning sites are located where the insertion of foreign DNA neither disrupts the plasmid’s ability to replicate nor inactivates essential markers.
II. Virtually any DNA Sequence can be cloned:
Nuclease cleavage at a restriction site opens, or linearizes, the circular plasmid so that a foreign DNA fragment can be inserted. The ends of this linearized plasmid are joined to the ends of the fragment so that the circle is closed again, creating a recombinant plasmid (Fig. 4.2). Recombinant plasmids are hybrid DNA molecules consisting of plasmid DNA sequences plus inserted DNA elements (called inserts).
Such hybrid molecules are also called chimeric constructs or chimeric plasmids (The term chimera is borrowed from mythology and refers to a beast composed of the body and head of a lion, the heads of a goat and a snake, and the wings of a bat.). The presence of foreign DNA sequences does not adversely affect replication of the plasmid, so chimeric plasmids can be propagated in bacteria just like the original plasmid. Bacteria often harbour several hundred copies of common cloning vectors per cell.
Hence, large amounts of a cloned DNA sequence can be recovered from bacterial cultures. The enormous power of recombinant DNA technology stems in part from the fact that virtually any DNA sequence can be selectively cloned and amplified in this manner. DNA sequences that are difficult to clone include inverted repeats, origins of replication, centromeres, and telomeres. The only practical limitation is the size of the foreign DNA segment: most plasmids with inserts larger than about 10 kbp are not replicated efficiently.
Bacterial cells may harbour one or many copies of a particular plasmid, depending on the nature of the plasmid replicator. That is, plasmids are classified as high copy number or low copy number. The copy number of most genetically engineered plasmids is high (200 or so), but some are lower.
III. Construction of Chimeric Plasmids:
Creation of chimeric plasmids requires joining the ends of the foreign DNA insert to the ends of a linearized plasmid (Fig. 4.2). This ligation is facilitated if the ends of the plasmid and the insert have complementary, single stranded overhangs. Then these ends can base-pair with one another, annealing the two molecules together.
One way to generate such ends is to cleave the DNA with restriction enzymes that make staggered cuts; many such restriction endonucleases are available. For example, if the sequence to be inserted is an EcoRl fragment and the plasmid is cut with EcoRl, the single stranded sticky ends of the two DNAs can anneal (Fig. 4.3).
The interruptions in the sugar- phosphate backbone of DNA can then be sealed with DNA ligase to yield a covalently closed, circular chimeric plasmid. DNA ligase is an enzyme that covalently links adjacent 3′-OH and 5′-PO4 groups. An inconvenience of this strategy is that any pair of EcoRI sticky ends can anneal with each other.
So, plasmid molecules can re-anneal with themselves, as can the foreign DNA restriction fragments. These DNAs can be eliminated by selection schemes designed to identify only those bacteria containing chimeric plasmids. Blunt-end ligation is an alternative method for joining different DNAs. This method depends on the ability of phage T4 DNA ligase to covalently join the ends of any two DNA molecules (even those lacking 3′- or 5′-overhangs) (Fig. 4.4).
Some restriction endonucleases cut DNA so that blunt ends are formed. Because there is no control over which pair of DNAs are blunt end and ligated by T4 DNA ligase, strategies to identify the desired products must be applied.
A great number of variations on these basic themes have emerged. For example, short synthetic DNA duplexes whose nucleotide sequence consists of little more than a restriction site can be blunt-end ligated onto any DNA. These short DNAs are known as linkers. Cleavage of the ligated DNA with the restriction enzyme then leaves tailor-made sticky ends useful in cloning reactions (Fig. 4.5). Similarly, many vectors contain a poly-linker cloning site, a short region of DNA sequence bearing numerous restriction sites.
IV. Promoters and Directional Cloning:
Note that the strategies discussed thus far create hybrids in which the orientation of the DNA insert within the chimera is random. Sometimes it is desirable to insert the DNA in a particular orientation. For example, an experimenter might wish to insert a particular DNA (a gene) in a vector so that its gene product is synthesized. To do this, the DNA must be placed downstream from a promoter.
A promoter is a nucleotide sequence lying upstream of a gene that controls expression of the gene. RNA polymerase molecules bind specifically at promoters and initiate transcription of adjacent genes, copying template DNA into RNA products.
One way to insert DNA so that it will be properly oriented with respect to the promoter is to create DNA molecules whose ends have different overhangs. Ligation of such molecules into the plasmid vector can only take place in one orientation, to give directional cloning (Fig. 4.6).
V. Biologically Functional Chimeric Plasmids:
The first biologically functional chimeric DNA molecules constructed in vitro were assembled from parts of different plasmids in 1973 by Stanley Cohen, Annie Chang, Herbert Boyer, and Robert Helling. These plasmids were used to transform recipient E. coli cells (transformation means the uptake and replication of exogenous DNA by a recipient cell).
The bacterial cells were rendered somewhat permeable to DNA by Ca2+ treatment and a brief 42°C heat shock. Although less than 0.1% of the Ca2+ treated bacteria became competent for transformation following such treatment, transformed bacteria could be selected by their resistance to certain antibiotics (Fig. 4.7). Consequently, the chimeric plasmids must have been biologically functional in at least two aspects: they replicated stably within their hosts and they expressed the drug resistance markers they carried.
In general, plasmids used as cloning vectors are engineered to be small, 2.5 kbp to about 10 kbp in size, so that the size of the insert DNA can be maximized. These plasmids have only a single origin of replication, so the time necessary for complete replication depends on the size of the plasmid.
Under selective pressure in a growing culture of bacteria, overly large plasmids are prone to delete any nonessential “genes,” such as any foreign inserts. Such deletion would thwart the purpose of most cloning experiments. The useful upper limit on cloned inserts in plasmids is about 10 kbp. Many eukaryotic genes exceed this size.
2. Bacteriophage I as a Cloning Vector:
The genome of bacteriophage λ (lambda) is a 48.5 kbp linear DNA molecule that is packaged into the head of the bacteriophage. The middle one-third of this genome is not essential to phage infection, so λ phage DNA has been engineered so that foreign DNA molecules up to 16 kbp can be inserted into this region for cloning purposes.
In vitro packaging systems are then used to package the chimeric DNA into phage heads which, when assembled with phage tails, form infective phage particles. Bacteria infected with these recombinant phage produce large numbers of phage progeny before they lyse, and large amounts of recombinant DNA can be easily purified from the lysate.
3. Cosmids:
The DNA incorporated into phage heads by bacteriophage λ packaging systems must satisfy only a few criteria. It must possess a 14-bp sequence known as cos (which stands for cohesive end site) at each of its ends, and these cos sequences must be separated by no fewer than 36 kbp and no more than 51 kbp of DNA. Essentially any DNA satisfying these minimal requirements will be packaged and assembled into an infective phage particle.
Other cloning features such as an ori, selectable markers, and a poly-linker are joined to the cos sequence so that the cloned DNA can be propagated and selected in host cells. These features have been achieved by placing cos sequences on either side of cloning sites in plasmids to create cosmid vectors that are capable of carrying DNA inserts about 40 kbp in size (Fig. 4.8). Because cosmids lack essential phage genes, they reproduce in host bacteria as plasmids.
4. Fosmids:
Vector containing the single copy E.coli F-factor replicon, developed as an improved method for constructing libraries of cosmid-sized (approximately 40 kb) clones. The stability of inserts cloned into fosmid vectors has been shown to be substantially greater than in high copy vectors. Copy control fosmids, e.g., pCC1fos, contain both the E. coli F-factor replicon and the oriV high-copy origin of replication, thus providing the user the clone stability afforded by single-copy fosmid cloning and the high yields of DNA that can be realized from cosmid clones.
5. Phagemid:
A phage-plasmid vector is able to replicate as single- or double-stranded DNA. Phagemids can be induced to produce phage particles containing single-stranded DNA. Example: pBluescript series (Stratagene), which contains a filamentous f1 phage inter-genic region including the origin of replication.
6. Shuttle Vectors:
Plasmids used in eukaryotes require a eukaryotic origin of replication and marker genes that will be expressed by eukaryotic cells. At present plasmids are used for cloning in yeast and in plants. Although the yeast has a natural plasmid called the 2 µ circle, this is too large for use in cloning.
Plasmids such as yeast episomal plasmids (Yep) have been created by genetic manipulation using replication rigins from the 2 µ circle, and by incorporating a gene that will complement a defective gene in the host yeast cell. Strain of such yeast with defective gene can be used as a selectable marker for the presence of that plasmid. Yeast, like bacteria, can be grown rapidly, hence well suited for use in cloning. Particular use has been the creation of shuttle vectors which has origin of replication for yeast and bacteria like E.coli.
Shuttle vectors are plasmids capable of propagating and transferring (“shuttling“) genes between two different organisms, one of which is typically a prokaryote (E. coli) and the other a eukaryote (for example, yeast). Shuttle vectors must have unique origins of replication for each cell type as well as different markers for selection of transformed host cells harbouring the vector (Fig. 4.9). Shuttle vectors have the advantage that eukaryotic genes can be cloned in bacterial hosts, yet the expression of these genes can be analyzed in appropriate eukaryotic backgrounds.
7. Artificial Chromosomes:
DNA molecules 2 mega base pairs in length have been successfully propagated in yeast by creating yeast artificial chromosomes or YACs. Further, such YACs have been transferred into transgenic mice for the analysis of large genes or multi-genic DNA sequences in vivo, that is, within the living animal.
For these large DNAs to be replicated in the yeast cell, YAC constructs must include not only an origin of replication (known in yeast terminology as an autonomously replicating sequence or ARS) but also a centromere and telomeres.
Recall that centromeres provide the site for attachment of the chromosome to the spindle during mitosis and meiosis, and telomeres are nucleotide sequences defining the ends of chromosomes. Telomeres are essential for proper replication of the chromosome.
